1) Automatically identify 7 types of Impact devices for special application
2) Freely switch to hardness scales HRB, HRC, HV, HB, HS,HL
3) Direct calibration on HL,HRC,HB.
4) Test at any angle, even upside down
5) Large LCD screen with back-light, showing all functions and parameters
6) Upper and lower limit and sound alarm
7) Conversion to tensile strength (U.T.S)
2) Freely switch to hardness scales HRB, HRC, HV, HB, HS,HL
3) Direct calibration on HL,HRC,HB.
4) Test at any angle, even upside down
5) Large LCD screen with back-light, showing all functions and parameters
6) Upper and lower limit and sound alarm
7) Conversion to tensile strength (U.T.S)
| Model | 110 | 120 | 130 |
| Measuring Range | (170-960)HLD,(17.9-69.5)HRC,(19-683)HB,(80-1042)HV, (30.6-102.6)HS, (59.1-88)HRA, (13.5-101.7)HRB | ||
| Hardness parameter | HL, HRC,HRB, HS,HB,HV | ||
| Accuracy | Within±0.5%(HLD=800) | ||
| Display | LCD with back-light | ||
| Memory | 1250 groups | ||
| PC Connection | No | Available | |
| Printer | No | ||
| Battery | 2 AAA | ||
| Operating Temperature | -20℃~+60℃ | ||
| Dimensions | 129×68×25mm | 130×70×25mm | |
| Shell | Plastic | Metal | |
| Impact Device Type | Fixed D | D,DC,DL,D+15,G,C,E | |
| Weight | 230g | 240g | 300g |
| Standard Delivery | Main unit,Impact Device type D,Operation manual, Power adapter,Small supporting ring,Cleaning brush, Calibration block,Certificate. | ||
| Optional Accessories | Impact DC,D+15,DL,G,C,E(leeb120),Shaped support ring,Software | ||
